AMD Ryzen 5 8500G Processor with Radeon Graphics

Description

Model AMD Ryzen 5 8500G Platform Desktop Product Family AMD Ryzen Processors Product Line AMD Ryzen 5 8000 G-Series Desktop Processors with Radeon Graphics AMD PRO Technologies No Consumer Use Yes Regional Availability Global Former Codename "Phoenix" Architecture 2 x "Zen4", 4 x "Zen4c" # of CPU Cores 6 Multithreading (SMT) Yes # of Threads 12 Max. Boost Clock Up to 5.0GHz Base Clock 3.5GHz Max Zen4c Clock Up to 3.7GHz Zen4 Base Clock 4.1GHz Zen4c Base Clock 3.2GHz L2 Cache 6MB L3 Cache 16MB Default TDP 65W AMD Configurable TDP (cTDP) 45-65W Processor Technology for CPU Cores TSMC 4nm FinFET CPU Compute Die (CCD) Size 137mm² Package Die Count 1 Unlocked for Overclocking Yes AMD EXPO Memory Overclocking Technology Yes Precision Boost Overdrive Yes Curve Optimizer Voltage Offsets Yes AMD Ryzen Master Support Yes CPU Socket AM5 CPU Boost Technology Precision Boost 2 Instruction Set x86-64 Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 Max. Operating Temperature (Tjmax) 95°C *OS Support Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. Connectivity Native USB 4 (40Gbps) Ports 2 Native USB 3.2 Gen 2 (10Gbps) Ports 2 Native USB 2.0 (480Mbps) Ports 1 PCI Express Version PCIe 4.0 Native PCIe Lanes (Total/Usable) 14 / 10 NVMe Support Boot, RAID0, RAID1 System Memory Type DDR5 Memory Channels 2 Max. Memory 256GB System Memory Subtype UDIMM Max Memory Speed 2x1R DDR5-5200 2x2R DDR5-5200 4X1R DDR5-3600 4x2R DDR5-3600 Graphics Capabilities Integrated Graphics Yes Graphics Model AMD Radeon 740M Graphics Core Count 4 Graphics Frequency 2800 MHz DirectX Version 2.1 DisplayPort Extensions HDR Metadata Adaptive-Sync UHBR10 DisplayPort Max Refresh Rates (SDR) 7680x4320 @ 60Hz 3840x2160 @ 240Hz 3440x1440 @ 360Hz 2560x1440 @ 480Hz 1920x1080 @ 600Hz DisplayPort Max Refresh Rates (HDR) 7680x4320 @ 60Hz 3840x2160 @ 240Hz 3440x1440 @ 360Hz 2560x1440 @ 480Hz 1920x1080 @ 600Hz HDMI Version 2.1 HDCP Version Supported 2.3 USB Type-C DisplayPort Alternate Mode Yes Multi-Monitor Support Yes Max Displays 4 AMD FreeSync Yes Wireless Display Miracast Max Video Encode Bandwidth (SDR) 1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1 4320p60 8/10bpc AV1 Max Video Decode Bandwidth 1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264 2160p300 8bpc H.264, 4320p75 8bpc H.264 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1 AMD SmartAccess Memory Yes Warranty 3 Years
